4-Inch Square Electrical Box (1900 Box) — 4" x 4" x 2" Deep | Galvanized Junction Box (ETL)

4-Inch Square Electrical Box (1900 Box) — 4" x 4" x 2" Deep | Galvanized Junction Box (ETL)

Actual product specifications and colors may differ from the images displayed.

$3.77 CAD
$3.77 CAD
Sale Sold out
Shipping calculated at checkout.
Pack
Liquid error (sections/main-product line 548): Could not find asset snippets/pickup-availability.liquid
  • Local Delivery Icon Local delivery available for orders over $500
  • Package Icon Eligible for Shipping
View full details

High-capacity junction. Universal commercial standard.

Execute professional-grade circuitry with this 4-Inch Square Electrical Box, the industry-standard "1900 box" for commercial and residential junctions. Fabricated from robust 1.1mm galvanized steel, it offers superior crushing resistance and grounding continuity compared to plastic alternatives. Its deep 2-inch profile provides ample cubic volume for complex splices, wire nuts, and multiple conduit runs. Featuring versatile concentric 1/2" & 3/4" knockouts, this box adapts effortlessly to various conduit sizes, making it the go-to enclosure for surface-mounted exposed work or concealed device installations (requires mud ring).

Features
  • Commercial Standard: Known as a "1900 Box," this 4-inch square enclosure is the backbone of commercial electrical rough-ins for junctions and device mounting.
  • High Volume: The 2-inch depth allows for a higher wire fill capacity than standard 1-1/2" boxes, preventing overcrowding when splicing multiple circuits.
  • Versatile Knockouts: Equipped with concentric 1/2" and 3/4" knockouts on all sides, allowing for flexible conduit entry without the need for drilling or punches.
  • Multi-Purpose: Functions as a heavy-duty junction box for splicing wires or accepts a "Mud Ring" (Plaster Ring) to mount switches, outlets, or lighting fixtures.
  • Heavy-Gauge Steel: 1.1mm thick galvanized construction ensures a solid, crush-proof installation and excellent EMI shielding for sensitive electronics.
  • Grounding: Includes a raised ground bump or tapped hole for a secure 10/32 grounding screw connection.
Specifications
  • Dimensions: 4" H × 4" W × ~2" D.
  • Material: 1.1mm Galvanized Steel.
  • Knockouts: Concentric 1/2" & 3/4".
  • Volume: 30 cu. in.
  • Certification: ETL Listed (4009580).
  • Type: 4-Square / 1900 Box.
