Two Devices. One Solid Box.
The Nodexa 2-Gang Device Box puts two devices side by side in one rigid steel enclosure — the box for a switch-plus-receptacle, a pair of switches, or any spot where a single gang won't carry the load. Drawn from 1.1mm galvanized steel at 3 by 3-3/4 inches and 2-1/2 deep, it holds 25 cubic inches: real room for the extra conductors and pigtails a two-device box demands without crowding the makeup. The solid one-piece body stays square as you drive the screws, so the two devices and the cover plate line up clean — the detail that separates a tidy finish from a crooked one. Standard 1/2-inch knockouts open on the top, bottom, and back for conduit or NMD cable, and it accepts any standard 2-gang cover or device plate. ETL Listed under 4009580 for residential and commercial installation. It's a NorthLine Signature electrical part: stocked deep, priced for the contractor buying by the sleeve, built to keep a two-gang run square and simple.
Features
- Two-device capacity — houses two switches, receptacles, or dimmers side by side in one enclosure
- 25 cu. in. volume — room for the extra conductors and pigtails a two-gang makeup needs; confirm box-fill on crowded runs
- Solid one-piece body — stays square as you drive the screws, so devices and cover plate align clean
- 1.1mm galvanized steel — resists rust, crush, and twist better than plastic; maintains grounding continuity
- 1/2″ knockouts — on top, bottom, and back for flexible conduit or NMD cable entry (connectors sold separately)
- Standard 2-gang fit — accepts any standard 2-gang device cover, wall plate, or device combination
- ETL Listed (4009580) — certified for code-compliant residential and commercial installation
Specifications
- Gang Configuration: 2-Gang, Non-Gangable
- Dimensions: 3″ H × 3-3/4″ W × 2-1/2″ D
- Volume: 25 cu. in.
- Material: Galvanized Steel, 1.1mm
- Knockouts: 1/2″ (top, bottom, back)
- Mounting: New work / surface-mount
- Certification: ETL Listed (4009580)
