Two Branches, One Stack
ABS double sanitary tee for tying two opposing fixture branches into a single vertical stack — the back-to-back junction used where two fixtures, like a pair of lavatories or a back-to-back bath group, drain into the same stack. Each branch inlet enters with a curved sanitary sweep that turns flow downward, so both lines drain cleanly without catching at the joint. All four ends are hub sockets sized for Schedule 40 IPS ABS, solvent-welded for a rigid, sealed stack. It meets ASTM D2661 and CSA B181.1 and carries cUPC and NSF/ANSI 14 certification, the listings an inspector checks on a residential or light-commercial rough-in across the GTA. Stocked in 1½" for paired-fixture branch work. Double sanitary tees are non-pressurized DWV only; test hydrostatically, never with compressed air or gas.
Features
- Two sanitary sweep inlets — opposing branches both turn flow downward into one stack
- All-hub (hub × hub × hub × hub) — solvent-welds to ABS pipe on all four ends
- Back-to-back fixtures — the standard junction for paired lavatories or bath groups sharing a stack
- Schedule 40 IPS sizing — pipe seats to full socket depth on every hub
- ASTM D2661 + CSA B181.1 compliant — meets Canadian DWV code for residential and light-commercial
- cUPC + NSF/ANSI 14 certified — the listings inspectors check on a rough-in
- DWV service only — not for pressure; test hydrostatically, never with compressed air or gas
Specifications
- Fitting Type: Double Sanitary Tee
- Pattern: Two sanitary sweeps (opposing branches to stack)
- Connection: All-Hub (Hub × Hub × Hub × Hub)
- Material: ABS (acrylonitrile butadiene styrene)
- System: DWV (drain, waste, vent), non-pressurized
- Pipe Compatibility: Schedule 40 IPS ABS
- Available Sizes: 1-1/2"
- Joining Method: Solvent cement (ABS)
- Certifications: cUPC, NSF/ANSI 14, ASTM D2661, CSA B181.1
- Service Temperature: -40°F to 180°F (typical ABS DWV)
- Colour: Black
