LESSO ABS Dishwasher Wye — 1½" Hub × Hub × ½" Barb DWV
LESSO ABS Dishwasher Wye — 1½" Hub × Hub × ½" Barb DWV
Actual product specifications and colors may differ from the images displayed.
Couldn't load pickup availability
Pickup available at GD KennedyUsually ready in 2 hours
View store information
-
Local delivery available for orders over $500
-
Eligible for shipping
Dishwasher Drain, Clean Tie-In
ABS dishwasher wye for tying a dishwasher drain hose into the sink waste line under the counter — the compact fitting that solvent-welds into a 1½" ABS DWV run and presents a ½" barbed outlet for the appliance hose. The two hub ends bond to ABS pipe; the barb grips the flexible drain hose and holds it with a clamp. It's built for non-pressurized DWV service and meets ASTM D2661 and CSA B181.1, with the cUPC and NSF/ANSI 14 listings an inspector checks across the GTA. Many jurisdictions require a high loop or air gap on a dishwasher drain — most appliance makers specify roughly a 32" high loop where no air gap is used, so check local code before final connection. A clean, code-friendly way to branch a dishwasher into the sink drain without cutting in a separate tee and adapter.
Features
- 1½" hub × hub × ½" barb — solvent-welds into an ABS waste line and accepts a dishwasher drain hose on the barb
- Purpose-built tie-in — branches a dishwasher into the sink drain without cutting in a separate tee and adapter
- Barbed outlet — grips flexible ½" drain hose; secure with a clamp
- ASTM D2661 + CSA B181.1 compliant — meets Canadian DWV code for residential work
- cUPC + NSF/ANSI 14 certified — the listings inspectors check on a rough-in
- Code-aware — most jurisdictions require a high loop or air gap; appliance makers often specify a ~32" high loop
- DWV service only — not for pressure; test hydrostatically, never with compressed air or gas
Specifications
- Fitting Type: Dishwasher Wye
- Connection: 1-1/2" Hub × 1-1/2" Hub × 1/2" Barb
- Material: ABS (acrylonitrile butadiene styrene)
- System: DWV (drain, waste, vent), non-pressurized
- Pipe Compatibility: Schedule 40 IPS ABS
- Branch Outlet: 1/2" hose barb (dishwasher drain)
- Joining Method: Solvent cement (ABS) on hubs; clamp on barb
- Certifications: cUPC, NSF/ANSI 14, ASTM D2661, CSA B181.1
- Service Temperature: -40°F to 180°F (typical ABS DWV)
- Colour: Black
