Spigot Fit, Bolts Dialed In
ABS closet flange with a spigot outlet for setting a toilet over an ABS DWV stack — the spigot end carries the same outside diameter as pipe and inserts into a 3" fitting hub, so it solvent-welds in compact and seats the flange flush to the finished floor. The adjustable bolt ring rotates after the flange is cemented, letting you line the closet bolts up square to the wall before you set the bowl. It's a LESSO America ABS DWV fitting conforming to ASTM D2661 and CSA B181.1 with NSF/ANSI 14 and cUPC listings — the marks an inspector checks on a residential or light-commercial rough-in across the GTA. The wax or rubber seal and closet bolts are sold separately. DWV service only; test hydrostatically, never with compressed air or gas.
Features
- Spigot outlet — inserts into a 3" fitting hub for a compact, solvent-welded closet connection
- Adjustable bolt ring — rotates after cementing to square the closet bolts to the wall
- 4×3 sizing — 4" flange face to a 3" spigot connection, the standard toilet rough-in
- LESSO America ABS DWV — conforms to ASTM D2661 and CSA B181.1
- cUPC + NSF/ANSI 14 listed — the marks inspectors check on a rough-in
- Seal and bolts separate — wax or rubber seal and closet bolts are sold separately
- DWV service only — not for pressure; test hydrostatically, never with compressed air or gas
Specifications
- Fitting Type: Closet Flange (Adjustable Ring)
- Connection: Spigot (fits into a 3" hub)
- Size: 4" x 3"
- Material: ABS (acrylonitrile butadiene styrene)
- System: DWV (drain, waste, vent), non-pressurized
- Pipe Compatibility: Schedule 40 IPS ABS
- Joining Method: Solvent cement (ABS)
- Bolt Ring: Adjustable / rotating
- Certifications: cUPC, NSF/ANSI 14, ASTM D2661, CSA B181.1
- Service Temperature: -40°F to 180°F (typical ABS DWV)
- Colour: Black
